□ FEATURE

■  최대 해상도 4K지원

■  EDID 처리기술 적용

■  HDCP기능 적용

■  Hot Plug detection 지원

■  입력1, 출력2개의  DVI 포트지원

□ SPECIFICATION

■ DVI Input 1Connector

■ Resolution : Up to 3840 x 2160 (4K) / 10.2Gbps / 340Mhz

■ DVI Output  2Connector

■ DVI +5V Output 100mA, Over current Protection Circuit

■ LED Display  : Output Signal Active Display (Green LED)

                       Power On Display (Red LED)

■ 입력전원 : DC +5V, 1A(6W이하)

■ SIZE : 170mm×75mm×25mm(0.5Kg)

□ Certification

■ Korea Certification

    R-R-GEC-GS-200D (2018-08-28)
